Automatic circuit breaker 1p 20A PL6-C20/1 6kA EATON

Description Automatic circuit breaker 1p 20A PL6-C20/1 6kA EATON

Model: PL6-C20/1
Volator: Eaton
Number of poles: 1
Nominal flow (In): 20 A
Specification characteristics: C
Nominal limiting power (Icu): 6 kA
Nominal operating voltage (Ics): 6 kA
Nominal operating voltage (Ue) AC: 230 V
Strum type: AC
Nominal frequency: 50/60 Hz
Nominal Impulse voltage (Uimp): 4 kV
Stream exchange class: 3
Overvoltage category: III
Step of obstruction: 2
Mounting method: DIN-rail
Width: 1 module (17.5 mm)
Mounting position: Whatever
Step of protection (terminal): IP20
Protection stage (front part): IP40 (after installation in a cabinet)
Operating temperature range: -25 °C to +75 °C
Saving temperature range: -35 °C to +75 °C
Conductor cut (single-core): 1 - 25 mm²
Conductor cut (rich): 1 - 16 mm²
Terminal tightening torque: 2 Nm
Electrical wear resistance: 10,000 cycles
Mechanical wear resistance: 20,000 cycles
Compliance with standards: IEC/EN 60898-1
Indication of contact position: Color (red/green)
Trim of accessories: Yes
