Automatic circuit breaker 1p 4A PL7-C4/1 10kA EATON

Description Automatic circuit breaker 1p 4A PL7-C4/1 10kA EATON

Virobnik: EATON
Series: PL7
Model: PL7-C4/1
Product type: Automatic vimikach
Number of poles: 1
Nominal flow (In): 4 A
Connection characteristic: C
Nominal voltage (Icn): 10 kA
Nominal operating voltage (Ue): 230/400 V AC
Nominal insulating voltage (Ui): 440 V AC
Nominal impulse voltage (Uimp): 4 kV
Frequency: 50/60 Hz
Energy class: 3
Mechanical wear resistance: 20,000 cycles
Electrical wear resistance: 10,000 cycles
Protection level (housing): IP40
Protection level (clem): IP20
Operating temperature range: -25...+75 °C
Temperature range: -40...+80 °C
Mounting type: DIN rail (TH35)
Connection method: Screw terminals
Maximum conductor overcut (hard): 1...25 mm²
Maximum conductor overcut (bend): 1...25 mm²
Terminal tightening torque: 2.8 Nm
Width: 17.5 mm
Height: 80 mm
Glibin vbudovuvannya: 70.5 mm
Mass: 0.12 kg
Compliance with standards: EN 60898-1, IEC 60898-1
