Automatic circuit breaker 2p 40A PL6-C40/2 6kA EATON

Description Automatic circuit breaker 2p 40A PL6-C40/2 6kA EATON

Virobnik: EATON
Series: PL6
Device type: Automatic vimikach
Number of poles: 2
Nominal flow (In): 40 A
Application characteristics: C (5-10 In)
Nominal boundary commutation capacity (Icn): 6 kA
Nominal operating voltage (Ue): 230/400 V AC
Nominal insulation voltage (Ui): 440 V AC
Nominal impulse voltage (Uimp): 4 kV
Nominal frequency: 50/60 Hz
Energy class: 3
Compliance with standard: IEC/EN 60898-1
Nominal operating switching capacity (Ics): 6 kA
Electrical wear resistance: 4000 cycles
Mechanical wear resistance: 10,000 cycles
Operating temperature range: -25 to +55 °C
Saving temperature range: -35 to +75 °C
Steps of zakhistu (klem): IP20
Protection steps (after installation in the closet): IP40
Mounting method: DIN rail (EN 60715)
Overcut of the connected conductor (hard): 1-25 mm²
Cross-section of the connected conductor (bend): 1-16 mm²
Terminal tightening torque: 2.8 Nm
Connection type: Screw terminals
Width per number of modules: 2 (35 mm)
Installation depth: 70 mm
Height: 80 mm
Width: 35 mm
Vaga: 0.25 kg
Type of protection: Type of overvoltage, type of short circuit
Visibility of contact position indicator: Yes
