Automatic circuit breaker 1p 13A HL-C13/1 4.5kA EATON

Description Automatic circuit breaker 1p 13A HL-C13/1 4.5kA EATON

Product type: Automatic breaker
Series: HL
Number of poles: 1
Nominal flow: 13 A
Connection characteristic (curve): C
Nominal breaker (Icn): 4.5 kA
Limiting voltage (Icu): 4.5 kA
Operating voltage (Ics): 4.5 kA
Nominal operating voltage (Ue): 230 V AC
Nominal insulation voltage (Ui): 400 V
Nominal impulse vitrium voltage (Uimp): 4 kV
Nominal frequency: 50/60 Hz
Energy class: 3
Electrical wear resistance: 4000 cycles
Mechanical Wear resistance: 10000 cycles
Protection level: IP20
Operating temperature range: -25°C to +50°C
Saving temperature range: -40°C to +75°C
Operation Connectable hardwire (min.): 1 mm²
Crossing of the connected solid conductor (max.): 25 mm²
Crossing of the connecting solid conductor (min.): 1 mm²
Crossing of the connecting wire conductor (max.): 25 mm²
Clamp tightening torque: 2.8 Nm
Width in DIN modules: 1
Overall width: 17.5 mm
Overall height: 80 mm
Overall depth: 70 mm
Mounting method: On DIN rail
Standard Type: IEC/EN 60898-1
Overvoltage category: III
Disconnection principle: Thermomagnetic
Contact position indicator visibility: So
Weight: 0.12 kg
