Twilight relay with sensor EEN002, 230V/16A

Description Twilight relay with sensor EEN002, 230V/16A

Power supply: 230 V AC, 50/60 Hz
Maximum power supply: 16 A
Maximum power supply (resistive): 3680 W
Maximum lighting intensity (inductive/LED): 1000 W
Threshold adjustment range: 2 - 2000 Lux
Hysteresis specification: ±15%
Hours of exercise: 10 - 60 s
Vimknennya workout hour: 10 - 60 s
Tension reduced: < 1 W
Sensor type: Wine photo sensor
Sensor cable length: 1 m
Relay protection level: IP20
Sensor protection level: IP65
Relay operating temperature range: -25°C ... +50°C
Sensor operating temperature range: -40°C ... +60°C
Relay mounting method: On DIN rail
Sensor mounting method: Wall mounted
Crossing of connecting conductors: 0.5 - 2.5 mm²
Contact type: 1 normally open (NO)
Electrical life of contacts: 100,000 cycles
Mechanical life of contacts: 10,000,000 cycles
Housing material: Self-extinguishing plastic
Overall dimensions of the relay (HxWxD): 90 x 36 x 66 mm
Overall dimensions of the sensor (Diameter x D): 22 x 50 mm
Vaga: 150 g
