Hager 4P 25kA C-2A 4M Circuit Breaker, NRN402

Description Hager 4P 25kA C-2A 4M Circuit Breaker, NRN402

Virobnik: Hager
Series: NRN
Virobu type: Automatic vimikach
Product code: NRN402
Number of poles: 4P
Nominal flow (In): 2A
Application characteristics: C
Nominal voltage (Icu): 25kA
Nominal operating voltage (Ics): 25kA
Nominal operating voltage of the exchanger (Ue): 230/400V AC
Nominal insulation voltage (Ui): 500V
Nominal impulse voltage (Uimp): 6kV
Width in DIN modules: 4M
Outside width: 72 mm
Mounting type: DIN rail
Sputter type: Thermomagnetic
Energy class: 3
Electrical wear resistance: 10,000 cycles
Mechanical wear resistance: 20,000 cycles
Crossing of the connected hard cable: 1.5 - 25 mm²
Crossing of the connected cable: 1.5 - 16 mm²
Terminal tightening torque: 2.8 Nm
Protection level (front panel): IP40
Protection level (clem): IP20
Operating temperature: -25 to +70 °C
Storage temperature: -40 to +80 °C
Visibility during operation: up to 95%
Height: 83 mm
Glibin: 70 mm
Standard: EN 60947-2
