Hager ACA916D difavtomat 1P+N 6kA B-16A 10mA A

Description Hager ACA916D difavtomat 1P+N 6kA B-16A 10mA A

Article: ACA916D
Device type: Differential automatic switch (diffautomatic)
Pole configuration: 1P+N
Nominal strum: 16 A
Specification characteristics for superstrum: B
Nominal voltage (Icn): 6 kA
Nominal differential flow current (IΔn): 10 mA
Differential flow type: A
Nominal operating voltage: 230 V AC
Nominal frequency: 50/60 Hz
Width: 2 modules (36 mm)
Mounting: DIN-rail
Type of clamps: Screw
Maximum cable overcut (flexible): 25 mm²
Maximum cable overcut (hard): 35 mm²
Mechanical wear resistance: 20000 cycles
Electrical wear resistance: 10,000 cycles
Protection level: IP20
Operating temperature range: -25 to +40 °C
Safety standard: EN 61009-1
Contact position indication: So
Indication of application for differential flow: So
