Shield Univers IP44/II 800x800x161mm 180mod.(3x60)

Description Shield Univers IP44/II 800x800x161mm 180mod.(3x60)

Protection level IP: IP44
Electrical safety class: II
Height: 800 mm
Width: 800 mm
Glibina: 161 mm
Number of modules: 180
Number of rows: 3
Number of modules per row: 60
Installation type: Prihovaniy
Housing material: Sheet steel
Door material: Sheet steel
Body color: White RAL 9010
Door colour: White RAL 9010
Number of doors: 1
Kut Door opening: 130°
The right direction for opening doors: So
Depth of niche for installation: 120 mm
Distance between DIN rails: 125 mm
Nominal flow: 250 A
Strength of grounding terminals (PE): 4 x 25 mm² + 52 x 16 mm²
Neutral terminal capacity (N): 4 x 25 mm² + 52 x 16 mm²
Mechanical protection stage: IK07
Operating temperature range: -5°C to +40°C
Range Temperature saving: from -25°C to +60°C
Maximum moisture content: 50% at +40°C
Lock visibility: Yes (key)
