Automatic circuit breaker 1p 32A HL-C32/1 4.5kA EATON

Description Automatic circuit breaker 1p 32A HL-C32/1 4.5kA EATON

Device type: Automatic vimikach
Virobnik: EATON
Series: HL
Number of poles: 1
Nominal flow In: 32 A
Characteristics of mitt splitting (curve): C
Nominal voltage Icn: 4.5 kA
Rated operating voltage Ue: 230 V AC
Nominal insulation voltage Ui: 440 V AC
Nominal impulse voltage Uimp: 4 kV
Strum type: Zmіnny (AC)
Nominal frequency: 50/60 Hz
Energy class: 3
Electrical wear resistance: 10,000 cycles
Mechanical wear resistance: 20,000 cycles
Protection level (housing): IP20
Mounting method: On DIN rail
Width (number of modules): 1
Operating temperature range: -25 to +50 °C
Saving temperature range: -40 to +75 °C
Maximum overcut of the connected conductor (hard/flexible): 1-25 mm²
Terminal type: Gvintovi
Terminal tightening torque: 2.8 Nm
Compliance with standards: EN 60898-1
Release mechanism: Thermal and electromagnetic
Contact position indication: Yes
