Automatic circuit breaker 3p 32A BZMB1-A32-BT 25kA EATON

Description Automatic circuit breaker 3p 32A BZMB1-A32-BT 25kA EATON

Device type: Automatic vimikach
Series: BZMB1
Model: BZMB1-A32-BT
Virobnik: EATON
Number of poles: 3
Nominal flow In: 32 A
Application characteristics: Thermomagnetic, fixed
Rated operating voltage Ue: 230/400 V AC
Maximum operating voltage Ue: 690 V AC
Nominal insulation voltage Ui: 690 V
Nominal impulse voltage Uimp: 8 kV
Nominal limiting voltage Icu (at 400V AC): 25 kA
Rated operating voltage Ics (at 400V AC): 25 kA (100% Icu)
Nominal frequency: 50/60 Hz
Stacking category: A
Compliance with standards: IEC/EN 60947-2
Mechanical wear resistance: 10,000 cycles
Electrical wear resistance: 6000 cycles (at 400V AC, In)
Step zakhistu terminal: IP20
Front panel protection level: IP40 (with terminal cover)
Operating temperature range: -25 °C to +70 °C
Saving temperature range: -40 °C to +85 °C
Installation type: Stationary, on a mounting panel
Connection type: Bolt terminals
Crossing of the connected cable (hard): 1.5 - 50 mm²
Terminal tightening torque: 3.5 Nm
Overall dimensions (WxHxD): 75 x 130 x 60 mm
Vaga: 0.9 kg
Indication of contact position: Yes (ON/OFF)
