Automatic motor protection switch 2p 1.6A Z-MS-1.6/2 EATON

Description Automatic motor protection switch 2p 1.6A Z-MS-1.6/2 EATON

Nominal flow (In): 1.6 A
Range of regulation of thermal sprayer: 1 - 1.6 A
Strum of electromagnetic spitter: 22.4 A (fixed)
Number of poles: 2
Nominal operating voltage (Ue): 690 V AC
Nominal operating voltage of continuous flow (Ue DC): 220 V DC
Nominal insulation voltage (Ui): 690 V
Nominal impulse voltage (Uimp): 6 kV
Rated maximum short-circuit voltage (Icu) at 230/240 V AC: 150 kA
Rated maximum short-circuit withstand capacity (Icu) at 400/415 V AC: 150 kA
Rated maximum short-circuit withstand capacity (Icu) at 440 V AC: 150 kA
Rated maximum short-circuit voltage (Icu) at 500 V AC: 10 kA
Rated maximum short-circuit voltage (Icu) at 690 V AC: 10 kA
Rated short-circuit operating voltage (Ics) at 230/240 V AC: 150 kA
Rated short-circuit operating voltage (Ics) at 400/415 V AC: 150 kA
Rated short-circuit operating voltage (Ics) at 440 V AC: 150 kA
Nominal working vimikayucha Short circuit rating (Ics) at 500 V AC: 10 kA
Rated short-circuit operating voltage (Ics) at 690 V AC: 10 kA
Spitter class: Class 10
Wiki category: AC-3
Housing protection level: IP00
Terminal protection level: IP20
Mounting method: On DIN rail
Connection type: Screw terminals
Single core conductor crossbar: 1 x 1 - 6 mm²
Retin of rich conductor with tip: 1 x 1 - 6 mm²
Terminal tightening torque: 1.7 Nm
Range of operating temperatures in the middle: -25 - +55 °C
Temperature range: -40 - +80 °C
Width: 45 mm
Height: 93 mm
Glibin: 76 mm
Vaga: 0.25 kg
Electrical wear resistance: 0.1 x 10^6 cycles
Mechanical wear resistance: 0.1 x 10^6 cycles
Compliance with standards: IEC/EN 60947-1, IEC/EN 60947-2, IEC/EN 60947-4-1
