Automatic circuit breaker 1p 4A PL6-C4/1 6kA EATON

Description Automatic circuit breaker 1p 4A PL6-C4/1 6kA EATON

Series: PL6
Number of poles: 1P
Nominal flow: 4 A
Connection characteristic: C
Nominal voltage: 6 kA
Nominal operating voltage of the exchanger: 230/400 V
Strum type: Zminniy
Nominal frequency: 50/60 Hz
Energy exchange class: 3
Electrical wear resistance: 10,000 cycles
Mechanical wear resistance: 20,000 cycles
Protection level IP (terminal): IP20
Protection stage IP (front side): IP40
Operating temperature range: -25 to +75 °C
Saving temperature range: -35 to +80 °C
Mounting type: DIN rail
Number of modules: 1
Maximum span of the connected cable (hard): 25 mm²
Maximum span of the connected cable (flexible): 16 mm²
Terminal tightening torque: 2 Nm
Compliance with standards: IEC/EN 60898-1
Installation instructions: Whatever
Height: 80 mm
Width: 17.5 mm
Mounting depth: 70 mm
