Hager load switch, enclosure up to 50 mm2, 3 pole 125 A, HA351

Description Hager load switch, enclosure up to 50 mm2, 3 pole 125 A, HA351

Nominal flow: 125 A
Number of poles: 3
Nominal operating voltage: 230/400 V AC
Nominal insulation voltage: 690 V AC
Nominal impulse voltage: 6 kV
Drying category: AC-22B
Maximum conductor span: 50 mm²
Mounting type: DIN rail
Number of modules: 4.5
Frequency: 50/60 Hz
Wash stream of a short zamikannya (with a prisoner gG 125A): 10 kA
Short-hour vitrium bath (Icw): 1.5 kA (1s)
Mechanical life: 20,000 cycles
Electrical life: 10000 cycles (at Ue 230V, In)
Terminal protection level: IP20
Protection step (from the front to the shield): IP40
Operating temperature: -20 to +50 °C
Storage temperature: -40 to +70 °C
Maximum altitude above the sea level: 2000 m
Terminal tightening torque: 3.5 Nm
I will adjust the height: 83 mm
Extension width: 78.5 mm
Glibin for extension: 70 mm
Performance standards: EN 60947-3, IEC 60947-3
