Hager load switch, modular up to 16 mm2, 4 pole 40 A, HAB404

Description Hager load switch, modular up to 16 mm2, 4 pole 40 A, HAB404

Type of device: Vimikach navantazhennya
Brand: Hager
Model: HAB404
Type of installation: Modular, on DIN rail
Number of poles: 4P
Nominal flow: 40 A
Nominal operating voltage (Ue): 230/400 V AC
Nominal insulation voltage (Ui): 500 V
Nominal impulse withstand voltage (Uimp): 4 kV
Frequency: 50/60 Hz
Maximum conductor overcut, hard: 25 mm²
Maximum overcut conductor, flexible: 16 mm²
Terminal type: Screw
Terminal tightening torque: 2.8 Nm
Electrical wear resistance: 10000 cycles
Mechanical wear resistance: 100000 cycles
Protection stage (terminal): IP20
Protection stage (front panel of the cabinet): IP40
Operating temperature range: from -20 to +50 °C
Saving temperature range: from -20 to +70 °C
Virginous moisture: up to 95% at 55 °C
Width in modules: 4
Standard: IEC/EN 60947-3
Congestion level: 3
Nominal short-circuit current (Icc): 6 kA (with front shutter gG 63A)
Indication Contact position: So (Vmk./Vimk.)
