Hager H250 Circuit Breaker. In=125A. 4 points, 70kA. LSI, HEC126H

Description Hager H250 Circuit Breaker. In=125A. 4 points, 70kA. LSI, HEC126H

Brand: Hager
Series: H250
Article: HEC126H
Type of device: Automatic vimicac with molded body (MCCB)
Number of poles: 4
Nominal flow (In): 125 A
Spitter type: Electronic
Spitter protection functions: LSI (type of revantage, short circuit with shutter, mitt)
Range of adjusting the thermal flow rate (Ir): 50 - 125 A (0.4 - 1 x In)
Range of adjusting the time of shutting down thermal protection (tr): 0.5 - 24 s
Adjustment range for short circuit protection (Isd): 1.5 - 10 x Ir
Adjustment range for short circuit shutdown time (tsd): 0 - 0.5 s
Range of adjustment of the mitten protection flow (Ii): 2 - 12 x In
Nominal operating voltage (Ue): 400 V AC
Maximum operating voltage: 690 V AC
Nominal frequency: 50/60 Hz
Nominal voltage Isolation (Ui): 750 V
Nominal impulse voltage (Uimp): 8 kV
Nominal limiting voltage (Icu) at 400V AC: 70 kA
Rated operating voltage (Ics) at 400V AC: 70 kA
Category: A
Installation type: Stationary
Connection type: Front screw
Mechanical wear resistance: 20,000 cycles
Electric Wear resistance: 10,000 cycles
Protection level (front panel): IP40
Protection level (clem): IP20
Operating temperature range: -25 to +70 °C
Saving temperature range: -40 to +85 °C
Standards: IEC 60947-2, EN 60947-2
Width: 140 mm
Height: 257 mm
Glibina: 141 mm
Vaga: 3.9 kg
