Hager load switch, case-mounted, 4-pin, 2500A, HA466

Description Hager load switch, case-mounted, 4-pin, 2500A, HA466

Nominal flow: 2500 A
Number of poles: 4
Nominal operating voltage (Ue): 690 V AC
Nominal insulation voltage (Ui): 1000 V
Nominal impulse voltage (Uimp): 12 kV
Nominal frequency: 50/60 Hz
Drying category: AC-23A
Nominal short-hour vitrification flow (Icw): 50 kA (1 s)
Nominal peak vitrification flow (Ipk): 100 KA
Mounting type: Wall-mounted, cabinet
Protection level (housing): IP65
Mechanical wear resistance: 5000 cycles
Electrical wear resistance: 1500 cycles (at nominal voltage)
Connection type: Bolt terminals
Maximum cable span: 2 x 400 mm² (per pole)
Operating temperature range: -25°C to +70°C
Temperature range: -40°C to +80°C
Water content: 95% at 55°C
Case material: Metal (steel)
Housing finish: Epoxy powder
Body color: Gray (RAL 7035)
Overall dimensions (HxWxD): 1000 x 600 x 350 mm
Vaga: 80 kg
Possibility of blocking: Yes (at the position "VIMK")
Compliance with standards: IEC/EN 60947-3
Handle type: Rotary handle
Position agility: 2 (UVIMK/VIMK)
Overvoltage category: IV
Zagalna power supply: 150 W
