Residual current circuit breaker 2p 16A FRBMM-C16/1N/001 10mA EATON

Description Residual current circuit breaker 2p 16A FRBMM-C16/1N/001 10mA EATON

Device type: Differential automatic (PZV+AV)
Virobnik: EATON
Series: FRBMM
Model: FRBMM-C16/1N/001
Number of poles: 2 (1P+N)
Nominal flow: 16 A
Nominal voltage: 230 V AC
Nominal frequency: 50 Hz
Vimknennya characteristic (curve): C
Nominal differential flow: 10 mA
Type of differential protection: A (for variable and pulsating steady streams)
Nominal switching capacity (Icn): 6 kA
Energy class: 3
Protection level: IP20
Type of application for differential strum: Mitteve
Hour of use for the differential strut: < 0.1 s
Resistance to pulse streams (8/20 µs): 250 A
Possibility of phase/neutral connection: Either side
Neutral connection: Yes
Mounting method: On DIN rail
Width: 2 modules DIN
Operating temperature range: -25 to +50 °C
Temperature range: -40 to +70 °C
Cross-section of the connected conductor (hard/light): 1 - 25 mm²
Terminal tightening torque: 2.8 Nm
Mechanical wear resistance: 20,000 cycles
Electrical wear resistance: 10,000 cycles
Appearance standard: EN 61009-1
Indication: Position of contacts (On/Vimk), application for differential strum
Terminal type: Gvintov
