Contactor 40A, 2HB, 230V Hager ESC240

Description Contactor 40A, 2HB, 230V Hager ESC240

Nominal operating flow (AC-1): 40 A
Contact configuration: 2 HB
Nominal coil voltage (Uc): 230 V AC
Coil frequency: 50 Hz
Nominal operating voltage (Ue): 250 V AC
Nominal insulation voltage (Ui): 440 V
Nominal impulse voltage (Uimp): 4 kV
Increased tension of the coil when switched on: 25 VA
The tension of the cat has been reduced when it gets tired: 4.4 VA
Electrical wear resistance (AC-1): 500,000 cycles
Mechanical wear resistance: 1,000,000 cycles
Operating temperature range: -10 to +50 °C
Temperature range: -40 to +70 °C
Protection level: IP20
Mounting type: DIN rail
Maximum overcut of hard cable: 1.5 - 10 mm²
Maximum cable cable cut: 1.5 - 6 mm²
Width: 2 modules (35 mm)
Height: 83 mm
Glibin: 60 mm
Compliance with standards: EN 61095
Overvoltage category: III
Congestion step: 2
Maximum switching voltage (AC-1, 230V): 9 kVA
