Contactor 40A, 4NC, 230V Hager ESC441

Description Contactor 40A, 4NC, 230V Hager ESC441

Nominal flow: 40 A
Number of head contacts: 4
Head contact configuration: 4NC
Nominal control coil voltage (Us): 230 V AC
Nominal operating voltage (Ue): 400 V AC
Nominal insulation voltage (Ui): 440 V
Nominal impulse voltage (Uimp): 4 kV
Frequency: 50/60 Hz
Increased tension of the cat (morning): 4.1 VA
Spozhivana coil tension (on): 28.5 VA
Put pressure on the pole at In: 1.5 W
Electrical wear resistance (AC-1, 230V): 100,000 cycles
Mechanical wear resistance: 1,000,000 cycles
Operating temperature range: -10 to 50 °C
Saving temperature range: -40 to 80 °C
Max. overcut of wire conductor: 10 mm²
Max. cross-cut of hard conductor: 16 mm²
Protection level (clem): IP20
Protection level (attachments near the housing): IP40
Mounting type: DIN rail
Width: 4 modules
Congestion step: 2
Overvoltage category: III
Nominal short-hour vitrification flow (Icw) 1s: 240 A
Nominal short-circuit current (Inc): 3 kA
Recommended zapozhnik for zakhistu: gG 50 A
Standard: IEC/EN 61095
Weight: 0.45 kg
