Automatic circuit breaker 1p 10A HL-B10/1 4.5kA EATON

Description Automatic circuit breaker 1p 10A HL-B10/1 4.5kA EATON

Device type: Automatic vimikach
Virobnik: EATON
Series: xPole Home
Model: HL-B10/1
Number of poles: 1
Nominal flow: 10 A
Connection characteristic: B
Nominal limiting voltage (Icn): 4.5 kA
Rated operating voltage (Ue): 230 V AC
Nominal insulation voltage (Ui): 440 V
Nominal impulse voltage (Uimp): 4 kV
Strum type: Zminniy (AC)
Frequency: 50/60 Hz
Electrical wear resistance: 4000 cycles
Mechanical wear resistance: 10,000 cycles
Energy exchange class: 3
Protection level (housing): IP40
Protection level (clem): IP20
Operating temperature range: -25 to +50 °C
Temperature range: -40 to +70 °C
Maximum overcut of the connected hard conductor: 25 mm²
Maximum cross-section of the connected wire conductor: 16 mm²
Terminal tightening torque: 2.0-2.4 Nm
Terminal type: Gvintovi
Mounting method: On DIN rail (EN 60715, TH35)
Width: 1 module (17.5 mm)
Overall dimensions (WxHxD): 17.5 x 80 x 70 mm
Vaga: 0.12 kg
Performance standards: EN 60898-1
Indication of contact position: So (red/green)
Overvoltage category: III
Congestion step: 2
Maximum installation height above the sea level: 2000 m
