Residual current circuit breaker ADA932D 1P+N 6kA B-32A 30mA Hager

Description Residual current circuit breaker ADA932D 1P+N 6kA B-32A 30mA Hager

Number of poles: 1P+N
Nominal current: 32 A
Specification characteristics: B
Nominal voltage: 6 kA
Nominal differential current: 30 mA
Type differential protection: A
Rated operating voltage: 230 V AC
Rated frequency: 50/60 Hz
Number of modules: 2
Mounting type: DIN rail
Maximum crossbar for hard cable: 25 mm²
Maximum cable span: 16 mm²
Terminal tightening torque: 2.8 Nm
Terminal protection level: IP20
Case protection level (after installation): IP40
Operating temperature range: -25 to +40 °C
Saving temperature range: from -40 to +70 °C
Electrical wear resistance: 10,000 cycles
Mechanical wear resistance: 20,000 cycles
Resistance to pulse jets (8/20 µs): 250 A
Short-hour training for differential jet: non-selective
Type of spray jet: Thermomagnetic
