Residual current relay (RCD) 4p 25A PF6-25/4/03 300mA EATON

Description Residual current relay (RCD) 4p 25A PF6-25/4/03 300mA EATON

Virobnik: EATON
Series: PF6
Device type: Differential relay (DRV)
Number of poles: 4P
Nominal flow (In): 25A
Nominal differential flow current (IΔn): 300mA
Type of differential strum: A
Nominal voltage (Un): 230/400V AC
Nominal frequency: 50/60Hz
Rated switching capacity (Inc): 10kA
Nominal value before immobilization/exposure at differential flow (IΔm): 1000A
Resistance to pulse current (8/20 µs): 250A
Selectivity class: Non-selective
Mounting type: DIN rail
Width: 4 modules
Protection level (housing): IP40
Protection level (clem): IP20
Operating temperature: -25°C to +40°C
Storage temperature: -35°C to +60°C
Overcut of the connected conductor (hard): 1.5 - 25 mm²
Cutting the connected conductor (bend): 1.5 - 16 mm²
Terminal tightening torque: 2.4 Nm
Mechanical wear resistance: 20,000 cycles
Electrical wear resistance: 10,000 cycles
Standard: IEC/EN 61008-1
Indication of contact status: Available
Indication of assignment: Nayavna (zhovty ensign)
